Security module.
Maximum applicable motor capacity: 0.4kw.
Power supply voltage: single phase AC100V.
Interface: MECHATROLINK- III communication command type (linear servo motor).
Design sequence: A.
Hardware specification: base mounting type (standard).
Matching (software): no matching (standard).
Matching (parameters): no matching (standard).
Optional module: security module.
European EC standards: Based on the integration of mechanical instructions standard ISO13849-1 EN,
Security module with individual standard 61800-5-2 IEC specified security function SGDV-200A01A000FT001
Through the combination of the SGDV servo unit, the best safety design of the mechanical system is realized.
Suitable for AC servo drive, with the following safety features specified in the international standard IEC61800-5-2 (Japan''s first).
Can easily achieve the best security design of mechanical systems.
Torque Off Safe (STO)
Stop Safe 1 (SS1)
Stop Safe 2 (SS2)
Limited Speed Safely (SLS)
Equipped with 2 security functions, can be set (distribution) security functions.
In addition, the monitoring time and other items can be changed through the parameter.
With the use of the servo unit with a security module, so that the system can be simplified and miniaturized. SGM7P type (rated speed: 3000r\/min) of inertia and flat servo motor in non speed reducer.
Rated output: 1.5kw.
Power supply voltage: AC200V.
Serial encoder: 24 bit delta.
Design sequence: IP65.
Shaft end: straight shaft, no keyway.
Optional parts: with oil seal, with brake (DC24V).
Yaskawa servo motor, also known as YASKAWA Yaskawa servo motor,
Origin of Japan, in Shenyang, China, Jiading, Shanghai also has a factory,
Is to make the position of the object, the position, the state and other output controlled,
Automatic control system capable of following an arbitrary change of an input target value (or a given value).
It is divided into AC servo motor and DC servo motor,
In the domestic semiconductor, liquid crystal manufacturing devices, electronic components packaging equipment, machine tools and general machinery has been widely used in.
As a leading enterprise for the first time Yaskawa servo drive, put forward the concept of "mechatronics",
Now has become a universal term
SGDV-200A01A000FT001 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=SGDV-200A01A000FT001&select=5
