Single axis servo driver SGD7S.
Maximum applicable motor capacity: 0.75kW.
Voltage: single phase \/ three phase AC200V.
Interface: MECHATROLINK-III communication command type (Chinese market is RJ-45 connector). ᥹఼
Design sequence: A.
Hardware purchase pieces: no purchase pieces.
It is helpful to the servo performance of ultra high speed and ultra precision control.
Maximize the performance of the device, to solve the problem SGDV-280D05B
Single axis servo unit.
Speed frequency response 3.1kHz.
Best use: in order to release the EX\/FT specifications.
Vibration suppression function.
For the inability to improve the speed loop gain of the machine,
Can reduce the velocity fluctuation by cogging motor.
Smooth driveServo motor SGMGH type.
Rated speed: 1500r\/min.
Power: 11Kw.
Power supply voltage: three phase AC200V.
Serial encoder: 17 bit relative value.
Design sequence: high precision machine tool.
Shaft end: straight shaft without key.
Optional parts: with DC24V brake.
High speed feed series: high speed running when no load.
Complete separation of the main circuit and the control circuit,
Alarm can only turn off the main circuit power supply, easy to maintain.
Parameter setting device.
The parameters can be directly entered by the servo drive body.
Saving wiring.
Using a serial encoder, encoder wiring number than the original product reduced by 1\/2.
Multi in one control: the use of the parameters of the switch can not use the torque, position, speed controlLarge capacity SGMVV type servo motor.
Rated output: 30KW.
Voltage: three phase AC200V.
Serial encoder: 20 bit delta.
Rated speed: 1500r\/min.
The main mechanical structure: flange type, straight shaft (with keyway and screw).
Optional parts: do not buy pieces.
The use of small, low inertia servo motor, also can give full play to the strength of the mechanical properties.
The new model SGMVV with a rated output of 22~55KW, the amount of passenger speed 800r\/min and 1500r\/min products.
After the motor is installed, the phase is started to run immediately.
Even if the servo is not adjusted, as long as the moment of inertia is within the allowable range,
Even if the load changes, it can be driven stably, and the vibration will not happen
SGDV-280D05B Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=SGDV-280D05B&select=5
