Servo motor SGMGH type.
Rated speed: 1500r\/min.
Power: 1.8kw.
Power supply voltage: three phase AC200V.
Serial encoder: 17 bit relative value.
Design sequence: high precision machine tool.
Shaft end: straight shaft with screw key.
Optional parts: with oil seal, DC24V brake.
High speed feed series: high speed running when no load Yaskawa SGDV-R90A01B000FT001.
Complete separation of the main circuit and the control circuit,
Alarm can only turn off the main circuit power supply, easy to maintain SGDV-R90A01B000FT001
Parameter setting device.
The parameters can be directly entered by the servo drive body.
Saving wiring.
Using a serial encoder, encoder wiring number than the original product reduced by 1\/2.
Multi in one control: the use of the parameters of the switch can not use the torque, position, speed controlSigma -v series servo unit SGDV Yaskawa SGDV-R90A01B000FT001.
Maximum applicable motor capacity: 0.5kw.
Power supply voltage: three phase AC400V.
Design sequence: B type.
Interface: MECHATROLINK- II communication command type (linear servo motor).
Matching (hardware): base mounting type (standard).
Realize real time communication.
The maximum transmission speed of 10Mbps and can be set to the communication cycle 250 s ~ 4ms,
Achieved a maximum of 30 stations in the high speed control Yaskawa SGDV-R90A01B000FT001. Through the high speed of communication,
Can send and receive all kinds of control information in real time.
Energy saving and high efficiency.
A maximum of 30 stations can be connected to the communication lines, can significantly reduce the wiring costs and time.
The command connector of the upper controller only needs 1,
Pulse generator for D/A converter or position instruction without speed / torque command.
High precision motion control is realized.
In addition to torque, position and speed control, but also to achieve high precision synchronization phase control.
Because the control mode can be switched on line, the complicated mechanical action can be realized more effectively and smoothly.High performance, use the best type of servo unit (high performance).
Maximum applicable motor capacity: 11kw.
Power supply voltage: three phase AC200V.
Design sequence: A.
Hardware specification: rack mounting type.
Interface: MECHATROLINK-III communication command type (rotary servo motor).
Function: no deviation standard.
High performance sigma shaped -V-EX series.
2 models of high performance servo uniit SGDV-R90A01B000FT001.
EX001 (support M- III high speed communication): the communication cycle is the minimum value of 125 s, which makes the response of the instruction becomes faster, and the track accuracy and processing ability are improved. SGDV-R90A01B000FT001.
EX002 (no deviation of the specification): greatly improve the command tracking performance, and further improve the accuracy of trajectory control.
